Wagner Intercooler Kit | 23+ Civic Type R FL5, 23+ Integra Type S DE5

Fits:

• 2023+ Honda Civic Type R FL5
• 2023+ Acura Integra Type S DE5

Supplied ready to install as a direct replacement for the factory intercooler. Includes intercooler, 2 reinforced silicone hoses, air shroud, mounting hardware, and assembly instructions.

_______

Wagner's intercooler core measures 580mm x 400mm x 70mm against the stock unit's 640mm x 160mm x 65mm — a smaller footprint in some dimensions but a massive 145% increase in charge air volume (16.2L vs. 6.6L) and 118% more surface area (2320cm² vs. 1064cm²). CAD-developed freeform cast aluminum end boxes optimize internal airflow, and the whole unit is rated to 6 bar of tested pressure resistance.

Every Wagner intercooler carries a high-quality anti-corrosion coating that also improves heat dissipation, meaning better cooling performance that holds up over the long term rather than degrading with age. The two included reinforced charge air hoses complete the upgrade path for the full charge air system.

Features

• 145% more charge air volume than stock (16.2L vs. 6.6L)
• 118% more core surface area than stock (2320cm² vs. 1064cm²)
• CAD-developed cast aluminum end boxes for optimized internal airflow
• Tested to 6 bar pressure resistance
• Anti-corrosion coating improves heat dissipation and long-term durability
• Direct replacement, ready to install — includes intercooler, 2 silicone hoses, air shroud, and hardware
