BlackVue DR590X Dash Cam | Universal
BlackVue DR590X Dash Cam | Universal
Couldn't load pickup availability
Over the years I've captured everything on dashcams from track days, to near-miss accidents, and security footage. Thankfully I've never been in a crash, but if I ever need footage from an impact I know I can rely on BlackVue to deliver it with crisp audio and video quality, as I've personally had one for over 5 years!!
Whenever I need footage I just open up my app and download what I need. I've even used the Live feature to view my car's surroundings from anywhere as I have it connected to various Wi-Fi setups at my home and the store. The optional LTE feature will let you view anywhere, anytime!
______
Full HD 60FPS video and Wi-Fi connectivity
The DR590X Front Camera records Full HD 1080p 60FPS videos at a 139-degree wide view angle. With the Sony STARVIS™ imaging sensor, you get awesome image clarity day and night.
You can easily adjust settings and transfer videos to your phone with the BlackVue App.
The USB port lets you connect a GPS receiver (optional).
60 frames per second recording
The DR590X-1CH records super fluid videos at a high frame rate of 60 frames per second.
This means videos look more lifelike and the dashcam can better catch details in fast moving objects thanks to reduced motion blur.
Native Parking Mode
With included Hardwiring cable
DR590X can be hardwired to your vehicle’s fuse panel for Parking Mode with the included Hardwiring cable. The dashcam will switch to Parking Mode automatically when vehicle ignition is turned off. Voltage cutoff and timer can be set in the BlackVue App.
Parking Mode accessories support
DR590X Series is also compatible with all BlackVue Parking Mode Kits and Batteries.
Built-in Impact & Motion Detection
Automatically tags important files
While driving, your BlackVue detects impacts and sudden changes in speed. While parked, it also detects movements*.
Use the filters in the BlackVue App and Viewer
All videos are tagged (Normal, Event, Parking Mode motion or time lapse), so that you can easily find the relevant ones in the BlackVue Viewer for Windows and Mac OS or the BlackVue App for Android and iOS.
External GPS Receiver (Optional)
The External GPS Receiver connects to the USB port to add speed and location data to your videos.
Speed: speed data–in Km/h or Mph–will be overlaid in the video (can be turned off in the settings).
Location: you can visualize the location of your vehicle in the BlackVue Viewer’s Map during video playback.
Manage Videos Easily with the BlackVue App and Viewer
The BlackVue App (iOS/Android) and Viewer (Windows/Mac OS) are free to download and use.
Both allow you to change settings and review videos sorted by time and type (Normal/Event/Parking).
With the BlackVue App, connect via Wi-Fi to your dashcam to retrieve videos on the spot.
What's included
- Front Camera
- Rear Camera
- Quick start guide
- Cable clips (5EA)
- microSD card
- microSD card reader
- Spare mount sticky pads
- Analog Video Cable
- Hardwiring power cable
- Cigarette lighter power adapter
- External GPS
| Specifications | |
|---|---|
| Model Name | DR590X-2CH With GPS |
| Channel |
2CH |
| Highlights |
Full HD (Front + Rear), Wi-Fi, External GPS, Sony Sensor |
| Product Dimensions |
Front: W 111.8 mm (4.40″) x H 34 mm (1.34″) / 87.8 (3.10 oz) |
| Rear Camera Connection |
Analog cable |
| Memory Support |
microSD card up to 256GB |
| Recording Modes |
– Normal, |
| Parking Mode |
YES (hardwiring cable included) |
| Parking Mode Event Voice Notifications |
YES |
| Imaging Sensor |
Front: Sony STARVIS™ CMOS Sensor (Approx. 2.1MP) |
| Viewing Angle |
Front: Diagonal 139°, Horizontal 116°, Vertical 61° |
| Resolution Frame Rate |
Front / Rear |
| Video Codec |
H.264 (AVC) |
| Image Quality and Bitrate Front/Rear |
Highest: 12+10 Mbps |
| Format Free |
YES (Adaptive) |
| Event File Overwrite Protection |
YES |
| SD Card Failure Alert |
YES |
| Scheduled Reboot |
YES |
| Video File Extension |
MP4 |
| Wi-Fi |
Built-in (802.11 b.g.n) |
| GPS |
External (Dual Band: GPS, GLONASS) |
| Microphone |
Built-in |
| Speaker |
Built-in |
| Impact Sensor |
3-Axis Acceleration Sensor |
| LED Indicators |
Front: Recording LED, GPS LED, Wi-Fi LED, Front Security LED |
| Button |
Button: Wi-Fi ON/OFF |
| Operation Temperature |
-20℃ – 70℃ (-4°F – 158°F) |
| Storage Temperature |
-20℃ – 80℃ (-4°F – 176°F) |
| High Temp Cut Off |
Approx. 70℃ (158°F) |
| Backup Battery |
Built-in supercapacitor |
| Input Power |
DC 12V-24V (DC Plug (Ø3.5 x Ø1.35)) to Wires (Black: GND/Yellow: B+/Red: ACC) |
| Power Consumption Hour |
Normal Mode (WiFi On/GPS On): 370mA/hour |
| Certifications |
Front: FCC, CE, RoHS, Telec, WEEE, IC |
| Software |
BlackVue Viewer |
| Application |
BlackVue Application (Android 5.0 or higher, iOS 9.0 or higher) |
| Others |
Adaptive Format-Free File Management System |
Recording time
| Model | Memory Capacity | Image Quality | Resolution |
|---|---|---|---|
| DR590X-2CH / DR590X-2CH IR |
Full HD @30fps + Full HD @30fps | ||
| 16GB | |||
| Highest | 1 HR 25 MIN | ||
| High | 1 HR 50 MIN | ||
| Normal | 2 HR 20 MIN | ||
| 32GB | |||
| Highest | 2 HR 50 MIN | ||
| High | 3 HR 40 MIN | ||
| Normal | 4 HR 40 MIN | ||
| 64GB | |||
| Highest | 5 HR 40 MIN | ||
| High | 7 HR 20 MIN | ||
| Normal | 9 HR 20 MIN | ||
| 128GB | |||
| Highest | 11 HR 20 MIN | ||
| High | 15 HR 40 MIN | ||
| Normal | 18 HR 40 MIN | ||
| 256GB | |||
| Highest | 22 HR 40 MIN | ||
| High | 31 HR 20 MIN | ||
| Normal | 37 HR 20 MIN | ||
| Bitrate (Mbps) Front + Rear | |||
| Highest | 12 + 10 | ||
| High | 10 + 8 | ||
| Normal | 8 + 6 |
