27WON Intercooler Upgrade | 17-21 Civic Type R FK8

Unity Performance is the exclusive Canadian dealer for 27WON Performance products. US customers, please purchase directly through 27WON.

Fits:

• 2017 - 2021 Honda Civic Type R (Hatch FK8)

Note: Compatible with factory charge pipes. Best paired with 27WON Boost Tubes. Also compatible with PRL Charge Pipe Upgrade Kit.

_______

The FK8's factory intercooler was designed to support ~320 hp — push beyond that on the street or track and it heat soaks quickly, causing the ECU to pull timing and rob power. The 27WON intercooler was developed after testing multiple core designs to find the best balance of flow and thermal efficiency for the Type R.

Core height was increased 41% (5.63" → 7.95") and thickness increased 47% (2.52" → 3.70"), maximizing the frontal area behind the grille. Results: +10 whp drop-in with no tuning, and up to +26 whp / +28 wtq with proper tuning.

Pair with the 27WON Silicone Boost Tubes for a complete front mount intercooler kit — includes 3 silicone pieces and all clamps. 4-ply reinforced silicone with integrated wire reinforcement for maximum strength. Includes an upgraded throttle body silicone that addresses a known failure point on the CTR.

Core Dimensions

• OEM: 5.63" H x 2.52" thick
• 27WON: 7.95" H (+41%) x 3.70" thick (+47%)

Features

• +10 whp no-tune drop-in | up to +26 whp / +28 wtq with tuning
• 41% taller, 47% thicker core vs. OEM — maximized frontal area
• Compatible with factory charge pipes and PRL Charge Pipe Kit
• Pairs with 27WON Boost Tubes for complete FMIC kit
• Boost tubes: 4-ply wire-reinforced silicone, upgraded throttle body silicone included
• Engineered and manufactured by 27WON Performance
